EXPLOSION PROOF MOTORS UL LISTED
(DUAL LABELED) NEMA PREMIUM
EFFICIENCY© C-FACE FOOTED
FEATURES:
•
Meets or exceeds NEMA Premium Efficiency Requirements
defined by NEMA MG1, Table 12-12
•
140TC - 210TC = Class I. Div I, Groups C & D: Max Amb =
40°C,55°C; Temp = T3C
•
250TC - 449TC = Class II, Div I, Groups F & G: Max Amb =
40°C; Temp = T3C
•
250TC - 449TC = Class I. Div I, Groups C & D: Max Amb = 55°C;
Temp = T2B
•
Totally Enclosed Explosion Proof (TEXP) Enclosure
1
UL Listed
·
CSA + C + US Certification
•
ISO 9001 Certification
•
140TC - 180TC = 9 Lead WYE 210TC - 405TC = 9 Lead Delta
•
440TC and up = 6 Lead WYE
•
Dual voltage ratings suitable for part wind start on lower voltage
•
1.15 Service Factor @ 60 hertz: 1.0 Service Factor @ 50 hertz
•
Vacuum Pressure Impregnation for all windings
•
Regreasable open bearings 254TC frame and above
•
Class F insulation system, class B rise at full load
•
Stainless steel nameplate and zinc plated hardware
•
Corrosion resistant epoxy paint
•
F1/F2 reversible
•
Feet are dual drilled for mounting flexibility
•
NEMA Design B performance
•
Sealed bearings thru 215TC frame
•
Severe Duty conversion kit available
•
Lifting provisions on 143TC frame and above
•
IP55 Protection
•
Lifting provisions on 143TC frame and above
•
Cast iron frame construction including the conduit box
APPLICATIONS:
General
purpose
use
on
pumps,
fans,
blowers,
compressors,
conveyors,
material
handling
and
other
industrial
machinery
installed
in
damp,
dusty
or
dirty
environments. These motors are designed to be used in hazardous locations as defined by Class and Group
Select RPM / Horsepower
EXPLOSION PROOF MOTORS UL LISTED
(DUAL LABELED) NEMA PREMIUM
EFFICIENCY© C-FACE FOOTED
FEATURES:
•
Meets or exceeds NEMA Premium Efficiency
Requirements defined by NEMA MG1, Table 12-12
•
140TC - 210TC = Class I. Div I, Groups C & D:
Max Amb = 40°C,55°C; Temp = T3C
•
250TC - 449TC = Class II, Div I, Groups F & G:
Max Amb = 0°C; Temp = T3C
•
250TC - 449TC = Class I. Div I, Groups C & D:
Max Amb = 55°C; Temp = T2B
•
Totally Enclosed Explosion Proof (TEXP) Enclosure
1
UL Listed
CSA + C + US Certification
•
ISO 9001 Certification
•
140TC - 180TC = 9 Lead WYE 210TC - 405TC = 9 Lead
Delta
•
440TC and up = 6 Lead WYE
•
Dual voltage ratings suitable for part wind start on lower
voltage
•
1.15 Service Factor @ 60 hertz:
1.0 Service Factor @ 50 hertz
•
Vacuum Pressure Impregnation for all windings
•
Regreasable open bearings 254TC frame and above
•
Class F insulation system, class B rise at full load
•
Stainless steel nameplate and zinc plated hardware
•
Corrosion resistant epoxy paint
•
F1/F2 reversible
•
Feet are dual drilled for mounting flexibility
•
NEMA Design B performance
•
Sealed bearings thru 215TC frame
•
Severe Duty conversion kit available
•
Lifting provisions on 143TC frame and above
•
IP55 Protection
•
Lifting provisions on 143TC frame and above
•
Cast iron frame construction including the conduit box
APPLICATIONS:
General
purpose
use
on
pumps,
fans,
blowers,
compressors,
conveyors,
material
handling
and
other
industrial
machinery
installed
in
damp,
dusty
or
dirty
environments.
These
motors
are
designed
to
be
used
in
hazardous locations as defined by Class and Group
Select RPM / Horsepower
